Centro Di Lavoro Orizzontale Mazak HCN 5000
Technical specifications
| CNC Model | Mazatrol |
| CNC version | Fusion 640 M |
| Spindle Taper toolholders | iso 40 |
| Power spindle | 30 Kw |
| RPM | 18000 |
| Number of tools | 80 |
| X-axis travel | 730 mm |
| Y-axis travel | 730 mm |
| Z-axis travel | 800 mm |
| Rapid linear axis feeds X Y Z | 60 m/min |
| Guide | Linear guide |
| Pallet dimensions | 500x500 mm |
| Pallet Type | continuous |
| Degrees pallet | 0,001 |
| Maximum load allowed | 500 Kg |
| High coolant pressure | yes |
| Cheap conveyor | Hinged Belt |
Basic information
| Code | 249A7A |
| Level of machine tool |
standard
|
| Brand | Mazak |
| Model | HCN 5000 |
| Construction year | 2006 |
Complete data sheet
Dimensioni max pezzo Ø800 × 1000 mmDimensions and weight
| Length | 5759 mm |
| Width | 2623 mm |
| Height | 2814 mm |
| Weight | 11430 Kg |
