Tornio Bimandrino Takamaz XW150
Technical specifications
| CNC Model | Fanuc |
| CNC version | 21iTA × 2 |
| Nose spindle | ASA 6 |
| Power spindle | 7,5 Kw |
| Max turning diameter | 300 mm |
| Spindle chuck diameter | 205 mm |
| Max turning lenght | 145 mm |
| Main spindle RPM | 4000 |
| RPM second spimdle | 4000 |
| Number tool posts on the 1th turret | 12 |
| Number of driven tool posts on the 1th turret | 12 |
| X-axis travel 1th turret | 160 mm |
| Z-axis travel 1th turret | 180 mm |
| Number tool posts on the 2th turret | 12 |
| Number of driven tool posts on the 2th turret | 12 |
| X-axis travel 2th turret | 160 mm |
| Z-axis travel 2th turret | 180 mm |
| Rapid linear axis feeds X Y Z | 16 m/min |
| High coolant pressure | yes |
| Gantry loader | yes |
| Material Stocker Systems | yes |
| Number of pallets | 12 x 2 |
| Cheap conveyor | Hinged Belt |
Basic information
| Code | B6B3AD |
| Level of machine tool |
standard
|
| Brand | Takamaz |
| Model | XW150 |
| Construction year | 2006 |
Complete data sheet
doppio gantry loader
Doppio Stoker
Scivolo per scarico pezzo finito o da controllare
ribaltatoreMachine equipment
set di portautensili fissi e motorizzatiDimensions and weight
| Length | 2360 mm |
| Width | 1660 mm |
| Height | 2180 mm |
| Weight | 6500 Kg |
