Elettroerosione A Filo LQ33W
Technical specifications
| CNC Model | Sodick |
| Tank dimension | 850 × 630 mm |
| EDM type | immersion |
| Wire diameters | 0,15 - 0,30 mm |
| Wire spool capacity | 8 Kg |
| X-axis travel | 370 mm |
| Y-axis travel | 270 mm |
| Z-axis travel | 250 mm |
| U-axis travel | 120 mm |
| V-axis travel | 120 mm |
| Max dimension piece | 570 x 419 mm |
| Max. work-piece weight | 453 Kg |
Basic information
| Brand | Sodick |
| Model | LQ33W |
| Construction year | 2005 |
| Working hours | 11534 |
| Code | A03774 |
| Level of machine tool |
standard
|
Dimensions and weight
| Length | 2108 mm |
| Width | 2184 mm |
| Height | 2134 mm |
| Weight | 3400 Kg |
