Tornio A Fantina Mobile Hanwha STL 38
Technical specifications
| CNC Model | Siemens |
| CNC version | 840 D |
| Power main spindle | 11 Kw |
| Main spindle bar diameter | 38 mm |
| sliding headstock travel (Z1) | 320 mm |
| Main spindle RPM | 8000 |
| Number of linear axes | 8 |
| Number of fixed tools Tool holder plate | 5 |
| Number of driven tools Tool holder plate | 4 |
| Rapid linear axis feeds X Y Z | 32 m/min |
| High coolant pressure | yes |
| Number of toolholders turrets/slides | 1 |
| Number tool posts on the 1th turret/slide | 10 |
| Number of driven tool posts on the 1th turret/slide | 10 |
| Tool holder type on the 1th turret/slide | VDI 30 |
| X-axis travel 1th turret/slide | 140 mm |
| Y-axis travel 1th turret/slide | + - 50 mm |
| Subspindle | yes |
| Sub spindle RPM | 8000 |
| Subspindle power | 11 Kw |
| Bar diameter | 38 mm |
| Z-axis travel sub spindle | 320 mm |
| Number of Back fixed tool posts | 4 |
| Coolant used | whole oil |
| Barfeeder model and brand | Iemca Boss 542 HD |
| Cheap conveyor | Hinged Belt |
| Number of driven tools included | 9 |
Basic information
| Code | 7E264B |
| Level of machine tool |
standard
|
| Brand | Hanwha |
| Model | STL 38 |
| Construction year | 2017 |
Machine equipment
dispositivo scarico pezzi lunghiDimensions and weight
| Length | 2685 mm |
| Width | 1620 mm |
| Weight | 4750 Kg |
